PRO-40 AD ATEX | Pneumatic Mag Drill

PRO 40 AD Atex machine has been designed to produce holes with annular cutters and 16 mm holes with twist drill bits that have a 19 mm (3/4″) Weldon shank. The combination of a pneumatic drive and a permanent magnetic base eliminates the need for an electric power supply. An extremely small ATEX-approved, pneumatic drill is perfectly suited to space-restricted and hazardous environments such as oil rigs, refineries, shipbuilding, and the petrochemical industry, where electric appliances are prohibited for safety reasons.

  • ATEX-approved materials. Safe for use in Ex zones and environments with hazardous, flammable, or combustible vapors, liquids, dust, or residues.
  • Strong permanent magnet. Secures the drill without the need for an electric supply.
  • Permanent magnetic base with V-shaped prismatic foot. Enables drilling on pipes from 250 mm upwards.
  • Innovative sliding ON/OFF pneumatic motor switch.
  • Mechanical safety lock. Prevents accidental motor activation.
  • Magnet ON/OFF indicator.
  • Ultra-low design. Perfect for space-restricted areas, with a height of only 185 mm.
  • Compact size and lightweight. Ideal for site work.
Download PDF Download Send Enquiry Email
PRO-40 AD ATEX | Pneumatic Mag Drill

Core drill

max 40 mm

Twist drill / Weldon Shank

max 16 mm (0.63’’) / with 19mm (0.75’’)

Depth of cut:

25 mm (0.98”)

Stroke

40 mm (1-1/2”)

Speed:

240 rpm

Compact design for space restricted areas

Protection against accidental motor start-up when the magnetic base is not activated

Clamping level indicator for safety and security

V-shaped prismatic mag base for pipe drilling

Feed handle can be fixed from either side

Max milling capacity 40 mm

Specification

Motor speed (under load)240 rpm
Motor power800 W
Weight15 kg (33 lbs)
Max milling capacity40 mm (1 37/64”)
Max drilling capacity16 mm (5/8”)
Stroke40 mm (1 37/64”)
Max depth of cut25 mm (63/64”)
Tool holder19 mm (3/4”) Weldon
Air consumption1400 l/min (50 CFM)
Pressure6 bar (87 psi)
Air connectionCEJN 410 DN 10.4 R 3/8” BSPT fi tting
for quick coupling
Minimum diameter of air hoses13 mm (33/64”)
Required ambient temperature0 – 40 °C (32 – 104 °F)
Cooling systemThrough spindle
Minimum workpiece thickness10 mm (25/64”)
Minimum pipe diameter*250 mm (9 27/32”)
Minimum pipe diameter*714 kgf (7000 N)
Magnetic base dimensions75 mm x 188 mm x 56 mm
(2 61/64” x 7 13/32” x 2 13/64”)
Potentially explosive atmosphereII 2G Ex h IIC 135°C (T4) Gb
II 2D Ex h IIIB T135°C Db
Overall dimensions LxWxH600 x 205 (with handle) x 185 [mm]
Product CodeWRT-0802-10-00-00-0
