PRO-72 | Two-Speed Drilling Machine

PRO-72 is a powerful 2-speed mag drill, enabling milling capacity up to 70 mm (2-3/4″) and drilling up to 25 mm (1″). Its rigid design extends tool life and semi-automatic gib adjustment enables the simple, fast, and correct operation to be done in a few easy steps. Thanks to the innovative lightweight smart magnet, PRO-72 weighs only 18.0 kg (40 lbs).

  • Rigid casting designed to withstand downward drilling force, prolonging the tool’s life
  • The motor stops when brushes are worn out (it is necessary to replace the brushes to restart the motor)
  • Semi-automatic gib adjustment enables simple, fast, correct, and repeatable slide backlash settings without any expert knowledge or experience
  • Energy Saving Base (ESB) uses only 50% of its power when the motor is not running
  • Magnetic Field Shape Control (MFSC) provides maximum holding power on thin materials
  • Magnetic Power Adhesion Control (MPAC) detects the adhesive force of the electromagnetic base and protects both the machine and the operator from working on too thin workpiece
PRO-72 | Two-Speed Drilling Machine

Max milling

capacity 70 mm

Max drilling

capacity 25 mm

Max depth

of cut 75 mm

Stroke

190 mm (7-1/2”)

Motor Speeds

160 rpm, 390 rpm

Milling capacity up to 70mm (2-3/4″)

Max depth up to 75 mm (3″)
Max stroke up to 190 mm (7-1/2″)

Drilling capacity up to 25 mm (1″)
The lightweight design of 18 kg (40 lbs) only

Specification

Motor Speeds (under load)160 rpm (gear I)
390 rpm (gear II)
Power1600 W
Weight18 kg (40 lbs)
Max milling capacity70 mm (2-3/4”) *
Max drilling capacity25 mm (1”)
Stroke190 mm (7-1/2")
Max depth of cut75 mm (3”) *
Voltage1~ 220–240 V, 50–60 Hz
1~ 110–120 V, 50–60 Hz
ESSS (Electronic Speed Stabilization System)yes
Semi-automatic gib adjustmentyes
MFSC (Magnetic Field Shape Control)yes
ESB – Energy Saving Baseyes
Magnet detachment safeguard yes
Magnetic clamping force (surface with the thickness of 25 mm and roughness Ra = 1.25)1122 kgf (11 000 N)
Magnet Base Dimensions92 mm × 180 mm × 54 mm
3-5/8" x 7" x 2-1/8"
Min. Workpiece Thickness8 mm (5/16)
SpindleMT3
Tool holder19 mm (3/4”) Weldon
Product Code 220–240 V, 50–60 HzWRT-0687-10-20-00-0
Product Code 110–120 V, 50–60 HzWRT-0687-10-10-00-0

If more than 60 mm (2-3/8″), use an MT3 arbor with 32 mm Weldon tool holder
(UCW-0686-08-00-00-0) and max depth of cut is 50 mm (2″)
