BM-7 Compact Plate And Pipe Beveller

Small and lightweight bevelling machine for milling plates, pipes, and contour profiles. Perfect solution for radius edge applying to steel sections before painting, to prevent rust build up on sharp edges. Quick, simple-to-use beveller that creates a perfect radius (R2, R3, R4 or R5) in just one pass, saving time and money over conventional grinding methods.

  • Lightweight and compact design
  • Small overall dimensions
  • Excellent for limited access
  • Continuous bevel width adjustments
  • Ideal for radius edge beveling
  • One single 45 degrees milling head for both radius and V bevels
  • 2 years of warranty
bm 7
bevel-width

Bevel width

max. 7 mm

bevel-angle

Bevel angle

45°, 30° (option)

countersinking

Countersinking

min. ID 40 mm

workpiece-thickness

Workpiece thickness

min. 5 mm

warranty-bevellers

Arched edge beveling with radius

Straight edge beveling with radius

Pipe beveling

Countersinking

Straight edge beveling with radius

Power supply 1~110-120 V, 50-60 Hz 1~220-240 V, 50-60 Hz
Motor 1080 W
Spindle speed (without load) 6200 rpm
Maximum bevel width (b) 7 mm (0.28”); Fig.1
Bevel angle (β, depending on milling head) 45°; 30° (option); Fig.1
Minimal diameter of countersinking ca 40 mm (1.6’’)
Rounding edges R2, R3, R4, R5; Fig. 2
Dimensions ( L x W x H) 339 mm (13.3”) x 135 mm (5.3”) x 320 mm (12,6”)
Weight (without milling head) 6.1 kg (13.45 lbs)
Product code (220-240 VAC) UKS-0717-10-20-00-0
Product code (110-120 VAC) UKS-0717-10-10-00-0

Case Studies

Small but mighty
machine

BM-7

country

Poland

description

This powerful and lightweight machine is perfect for precisely milling plates, pipes, and countersinking.
Quick, simple-to-use beveller BM-7 creates a perfect radius (R2, R3, R4 or R5) in just one pass, saving time and money over conventional grinding methods.
